Wireless Doorbell not working? Here is how to fix it

Is your Wireless Doorbell not working?

That sucks! Even the best wireless doorbells can fail.

Well thankfully, here is a rundown of common issues and how to troubleshoot!

Before we begin to go into troubleshooting steps to resolve any issue you have with your wireless doorbell, it is worth having a quick read of the How A Wireless Doorbell Works article.

Understanding how your wireless doorbell works is a major part of learning how to troubleshoot it. Once you know how it works, you can systematically go through each stage until you have resolved the issue, sent it back or just straight thrown it out.

Trending Wireless Doorbells

What Are The Symptoms?

Here are the common symptoms when you find your wireless doorbell not working:

  • Is the push button not working?
  • Is the chime not switching on?
  • Does it work intermittently?
  • Does it all switch on but the chime doesn’t sound?

Wireless Doorbell Not Working – Push Button Problems

Your push button is most likely to be the reason you have a wireless doorbell not working, just because:

  • It is the transmitter and initiates the process
  • It is usually outside, where it is exposed to more environmental factors

Wireless Communication Issues

The push button is the wireless transmitter. In other words, when you press the button, the signal travels up the antenna cable inside the push button unit and sends out a signal to be received by the chime.

In between the signal transmitter and the signal receiver are a number of things that can weaken or even destroy the signal before it can be received.

We refer to these as areas of interference and they can include:

  • Walls
  • Electrical Items
  • Other Wireless Items
  • Distance

Walls

Wireless doorbells will give you a range of operation, which is basically the furthest the transmitter and receiver can be apart.

Unfortunately, this range is ‘clear sight’ which means if there is nothing in the way, it will work.

Where there are walls in the way (walls in a house, who would have thought it!), then the signal is going to weaken slightly for every wall it needs to pass through.

If the wireless doorbell states that it works over a range of 1000 ft. then you should take 40% of that range it quite a few walls are going to be in the way.

For instance – 100ft with no obstructions, 40ft with multiple obstructions.

Electrical Items and Other Wireless Objects

Interference can be a huge problem with any wireless communication.

If you have a house full of wireless smart objects, then you may be getting some interference which will reduce the range of your wireless doorbell and may cause intermittent connectivity issues.

To troubleshoot interference issues with your wireless doorbell, make sure you identify any other wireless devices and switch them off.

Then test your doorbell.

If it works every time, switch each of the other devices on one by one until the problem returns.

Now you have identified the source of the issue, think about how you can adjust your setup to reduce interference.

Can you switch other devices to use another frequency? Can you move another device further away from the wireless doorbell transmitter/receiver? Are you in a position to move your wireless doorbell?

Distance

This one is obvious.

If you are having issues with your wireless doorbell, move it closer to the transmitter during your troubleshooting. If it works perfectly, move it further away, a few feet at a time, and continue to test.

Weather Damage

Some people will go for a wireless doorbell without checking to see if it is weatherproof. What you need, is a waterproof wireless doorbell that is rated IP44 or more to ensure it is not going to be damaged by water.

Environmental Factors

The push button is likely to be outside, which means it is exposed to environmental factors, such as:

  • Temperature extremes
  • Water damage from the rain
  • Wind Damage
  • Heat Damage
  • Damage from wildlife

Check your manual for the operating temperature range.

Do you live in a climate where it breeches either the minimal or maximum temperature? Has it reached those levels recently?

Is your push button waterproof? Wireless doorbells that are going to be exposed to the elements should have a protection rating of IP44, which means it is protected from water spray from all angles.

If you do not have a waterproof push button and it rains, it will break.

Has it been windy recently? Could anything have blown on to the push button which caused it to break?

Fixing A Wireless Doorbell

Wireless Doorbell Not Working – Chime Issues

When you have a wireless doorbell not working and you narrow the issue down to the chime, it can be frustrating. The chimes are quite difficult to troubleshoot, compared to a push button. Having said that, there are some things you can do though!

No Power To The Chime

Chimes are usually powered by a regular power socket, although they can also be battery powered, allowing for a more portable chime.

Mains Powered Chimes

If it is a mains powered chime, the first thing you will need to do is check for a power button on the chime, is it switched on?

Then move onto the actual power socket, is it working and switched on?

Plug something else into it to test and rule this out.

If you have a working socket but the wireless doorbell chime is still not working then check environmental factors.

If the wireless doorbell chime is in your house, it is likely to be well within the working temperature range (Specified in your manual).

Have you been away from your house and the central heating system has not been on? Is it possible that the temperature has dipped below the working range? If you live in a climate where this can happen, it is worth bearing in mind.

If the chime is out in a garage or a shed, this becomes more likely.

Battery Powered Chime

If the chime is battery powered, you will need to check to make sure you have actually turned it on!

It may sound simple, and you are likely to have checked this first, but you need to find the switch and make sure it is switched to the on position!

Flat Batteries

Exactly the same as any other battery-powered device, it will not work if you have flat batteries! Even if they are brand new batteries, check with another set to be sure, and to rule this out.

Check The Battery Compartment For Liquid

Liquid damage will cause all sorts of problems, especially when it has found its way into the battery compartment.

If you find some liquid in there, you then need to find out what the liquid is.

Any liquid is a concern!

If it is battery fluid, the batteries are faulty. You will need to clean out the battery terminal and then add in a new set of batteries.

If it is water, then you need to find out how it got in there to make sure it does not happen again.

Only when you are confident that you have fixed any water leak and completely dried the battery compartment, you can retest the wireless doorbell.

Any other liquid is sure to have come from a spillage! This can be quite common if you have a small child running around your house!

Make sure you keep your device away from any potential spillages.

Clean The Battery Connectors

The longer your wireless doorbell chime sits in the same position, not being moved regularly, the more dust and dirt it will collect.

If you are getting no power to the chime unit, then check the battery connectors to make sure there is nothing blocking the flow of energy from the battery.

Common battery terminal issues are caused by dust, dirt, and rust. Rust can form if it has been the victim of water damage in the past. As soon as you see rust, you should think about replacing the unit.

To clean the battery terminals, you will need some cotton swabs and some white vinegar. Then proceed with the following steps:

  • Dip the swab into the vinegar
  • Brush around the battery contacts until clean
  • Use a dry cloth to clean any excess fluid around the battery contacts

For newly purchased wireless doorbells, they may have added a plastic tag to stop the batteries from connecting during transit. Well worth checking for the plastic tag if it is a new unit which is not working!

Conclusion

If you have been through all of the above and you still having issues with your wireless doorbell, then maybe it is time to be thinking about buying a new one.

Take a look at our best wireless doorbell list for some ideas, and forget about your old wireless doorbell not working!

30 thoughts on “Wireless Doorbell not working? Here is how to fix it”

  1. My neighbour’s car key connects with my wireless door bell and it rings every time they use their car. Is there anything I can do to stop it?

    Reply
    • Hi

      Thanks for getting in touch!

      It is very likely that the remote car key is working on the same frequency as your wireless doorbell and may cause interference.

      Can you please let me know which wireless doorbell you have?

      Kind regards

      Reply
  2. I held the button on the outside one for 15 seconds & it broke the inside one that was working beautiful playing music Now neither one works

    Reply
    • Hi Elsie

      We are sorry to hear that you are having problems with your wireless doorbell.

      Which wireless doorbell do you have? Hopefully, we can help.

      Kind regards

      Reply
  3. My wireless door bell quit working aster just 2 months. I checked the battery in the button , it is good. It plugs in and is getting power as it lights up. I have pushed that little reset button. But it just does not chime’

    Reply
    • Hi Joyce

      I am sorry to hear that you are having problems with your wireless doorbell. What is the make and model of the doorbell? I will certainly do my best to help you out.

      Kind regards

      Reply
  4. My wireless doorbell has stopped working I have changed the batteries, doesn’t appear to be any damage.
    When I press the button I can see the light light up blue (which does only seem to appear on left side, not sure if it always did that though) but can’t get it to make a noise with receivers. They work and I have tried to pair but nothing.

    Thanks in advance
    David

    Reply
    • Hi David

      Thank you for getting in touch! What is the make and model of the doorbell please?

      The fact that you have a light on the transmitter is a good sign because it shows there is some activity. Do you have any buttons on the receiver? What happens when you press those, does it make any sound?

      Kind regards

      Reply
  5. Hello! Thanks for writing this. I have gone through and checked point by point but still my doorbell isn’t working. When the doorbell is pressed the little red light on it lights up but no chime. When I press the button on the receiver it chimes. Can you please help, or do I need to bin it and buy a new one? It’s a BY302. Thanks in advance 🙂

    Reply
    • Hi Rebecca

      Thanks for getting in touch! I would suggest starting again by matching the two units. Follow these instructions to see how you get on:

      1. Press and hold the volume button on the receiver for 6 seconds (it should beep twice)
      2. Press the doorbell push button

      If it responds then wait 60 seconds before pressing it again. Once 60 seconds have passed, try it a few times to see if it is still responding.

      You could also try adding a new battery into the push button, for reference, you will need a CR2032 battery 🙂 it could have just enough power to light up but not enough to send the signal.

      If you have tried both and it still fails then you could have a faulty push button or receiver, unfortunately.

      Please let us know how you get on with your faulty doorbell!

      Kind regards

      Reply
  6. i HAVE A SYSTEM WITH 3 CHIMES AND 2 DOORBELLS . THE DOORBELLS RING ONE CHIME BUT NOT THE OTHER 2 WHAT COULD BE ISSUE. i HAVE REPLACED BATTERIES IN ALL DOORBELLS AND NOTHING HAS CHANGED

    Reply
    • Hi Bob

      Thanks for contacting us! It sounds like the other 2 receivers have lost connection with the push button.

      If you can reply with the make and model I can give you instructions for resetting each receiver.

      Kind regards
      AWH

      Reply
  7. Hi, this is the second unit I have bought in 6 months, now the second one has stopped working. I have changed the batteries in the receiver and the push button. The blue light comes on but still it will not work. I am not very happy as they are not cheap to buy

    Reply
    • Hi

      Which unit do you have please?

      Most wireless doorbells have a warranty (12 or 18 months) so hopefully, the unit that you are having issues with is still covered.

      Kind regards
      AWH

      Reply
  8. I’ve got a wireless doorbell that came with my house, the PCB says P/N: 085-6150-03 rev A if that’s of any use. Just put fresh batteries in both the doorbell and transmitter, and it only works from about 3″ away. Not exactly what I’d call useful. Do you have any tips on how to troubleshoot the range, or did I just waste $10 in new batteries?

    Thanks!

    Reply
    • Hi Jonathan

      It seems that PCB is linking to an old Heath Zenith doorbell (SL-6150).

      If it is that model, it does have a warranty but I expect that to have expired by now as it is the older model.

      The fact that the doorbell now only works from a very close range indicates 1 of 2 things; Either there is not much power getting to the transmitter, or the transmitter itself is failing. It sounds like it is not able to generate enough power to transmit the signal over to the receiver.

      The only thing you can do, other than buying a new doorbell, is to ensure the battery contacts and clean and rust free. If they are clean, and the batteries are good, it sounds like a problem with the transmitter which cannot be fixed, unfortunately.

      Kind regards
      AWH

      Reply
  9. Assistance please: I have a Jackson WC8181. It was working – now it is not working. I have replaced all 3 batteries. The chime unit operates manually, so I am assuming the problem is with the bell push unit.
    I have second problem – last night and again this morning the chin unit began chiming and did so every 10 seconds or so until I removed the batteries.

    Reply
    • Hi

      Thank you for getting in touch!

      You mentioned that you changed the batteries, does that include in the bell push unit? It is possible that the 10-second chime could indicate a low battery. It could also indicate interference. Have you installed any other wireless device recently? I had a wireless doorbell that chimed each time my neighbor locked and unlocked their car!

      I notice as well that this particular model does not specify any waterproof rating. If it is not waterproof, it could be water damaged.

      It would be worth contacting the manufacturer directly at support@ji.com.au to see if they can offer any assistance.

      Kind Regards
      AWH

      Reply
  10. I have a 1byone wireless door chime R/X SKU: o00QH-0013.
    It has worked for a year but now each unit has new batteries and light up/chime independently but the push button doesn’t make the chime work.

    Reply
  11. I have a wireless b which has worked well but now the chime will only work when close to the bell push and I need it to work when I am further away. Does this mean I need a new one or is there a way to fix it. Thank you

    Reply
    • Hi

      That is a symptom of one of 3 things. Either:

      The doorbell batteries need replacing (there is not enough power to send the wireless signal) or;
      The transmitter or receiver is faulty (the transmitter is not sending a strong enough signal, or the receiver is not able to pick up the signal) or;
      Battery connections are damaged (it could be water, etc)

      It is worth checking the battery compartment for signs damage, and replacing the batteries in the transmitter. If you have changed the batteries, cleaned the battery compartment and your wireless doorbell is still not working, then you should consider replacing it.

      Kind regards
      AWH

      Reply
  12. Hi i have a byron by201f, i have put new batteries in both the push button and the receiver , they both have power but do not recognise each other. I dont appear to have a sync button either. I have tried to find a manual on line but have been unsuccessful so far, can you help?

    Reply
    • Hi

      The instructions for the Byron BY201F are as follows:

      1. Hold the volume button on the receiver for 6 seconds (you should hear a beep-beep)
      2. Press the transmitter button within 60 seconds

      Hope that helps! If not, you can find the BY201f manual here.

      Kind regards
      AWH

      Reply
  13. I have -Model NO: QH-823AC
    WIRELESS DOOR CHIME – Auto-learning Code Door Chime
    This unit is new – it will only work in one of my power sockets. I want to use a closer one but it will not chime – it lights up on the button The socket works fine with other devices – There is a bit of a wall that it is behind but it is actually next to an open archway about 10 feet from the button and will not chime
    Should these units work from a power board?

    Thank you

    Reply
    • Hi

      I think I have found your device (QH-832AC Manual)

      Looking at the specs of your wireless doorbell, it should work from any power socket, as long as it is:

      Power: AC220~240V

      As you mentioned, other devices work in the same socket so it is unlikely to be that. The only thing I can think of is that there is something close by that is causing interference, or blocking the signal. Do you have any large appliances near the socket you want to use?

      If you have, it might be worth switching those off temporarily (if you can) just to test.

      If you are still having issues, or you cannot find the fault then I suggest contacting the manufacturer: JIMMY@QUHWA.COM

      Kind regards
      AWH

      Reply
